NEMA-200B Small Tablet Dechlorination Diffuser

The NEMA-200B is a compact, all-in-one dechlorinating diffuser designed for potable water applications with lower flow rates of 150–200 gpm. Made of aluminum, it weighs just 5½ pounds and measures 8.5" × 4" × 7". A brass 2½" FNST swivel provides quick and secure connection to a hydrant or hose.

This device is intended for use only with flowing water from municipal potable water systems operating below 75 psi and flows under 1,000 gpm. Other uses may result in damage or injury.

Specifications

• Measures 8.5" × 4" × 7"
• Weighs just 5½ pounds
• Handles flows from 150 gpm to approximately 200 gpm
• Brass 2½" FNST swivel
• Holds up to three Vita-D-Chlor Tablets
• Made of aluminum
• Optional extension tube available for additional tablet capacity

Applications

• Designed for use with the dissolve rate of Vita-D-Chlor Tablets
• Some applications may also accommodate Vita-D-Chlor Slo-Tabs or other dechlorination tablets
• Ideal for lower-flow potable water dechlorination applications
• Compact design is optimized for flow rates between 150 and 200 gpm
